Nhsc2017-003a

Herschel's View of the Taurus Molecular Cloud Annotated

This mosaic combines several observations of the Taurus Molecular Cloud performed by ESA's Herschel Space Observatory. Located about 450 light-years from us, in the constellation Taurus, the Bull, this vast complex of interstellar clouds is where a myriad of stars are being born, and is the closest large region of star formation.

Observing the sky at far-infrared and sub-millimetre wavelengths from 2009 to 2013, Herschel could catch the faint glow of dust grains dispersed through these clouds. Astronomers can use this glow to trace the otherwise dark gas where star formation unfolds.

The darker, blue-hued areas throughout the image correspond to colder, less dense portions of the cloud, while the brighter, red-hued regions are the densest environments, where the star-forming activity is most intense.

The densest regions are distributed along an intricate network of filaments, teeming with bright clumps: the seeds of future stars. This is a textbook example of the filamentary structures that were spotted by Herschel nearly everywhere in the Galaxy, demonstrating the key role of filaments in star formation.

Embedded in the bright clump towards the top left of the image is Lynds 1544, a pre-stellar core that will later turn into a star. Here, Herschel detected water vapour the first time this molecule was ever found in a pre-stellar core in an amount that exceeds, by over 2000 times, the water content of Earths oceans.

Herschel observations of the tangled structures in the top right of the image have shown that the material along filaments is not at all static. In fact, the most prominent filaments appear to be drawing matter from their surroundings through a network of lower-density filaments, known as striations, perpendicular to the main filament. In these regions, astronomers found that magnetic fields tend to be perpendicular to the densest, star-forming filaments and parallel to the striations, indicating that they must also play an important role in the processes that lead to stellar birth.

This four-colour image combines Herschel observations at 160 microns (blue), 250 microns (green), 350 microns (split between green and red) and 500 microns (red), and spans 13.8 by 7.3; north is up and east to the left.

Image Details
Date
September 19, 2017
ID
nhsc2017-003a
Type
Observation
Credit
ESA/Herschel/NASA/JPL-Caltech CC BY-SA 3.0 IGO; Acknowledgement: R. Hurt (JPL-Caltech)
Object Details
Name
Taurus Molecular Cloud
Distance
Lightyears 450
Constellation
Taurus
Color Mapping
Telescope Spectral Band Color Assigment Wavelength
Herschel (PACS) Infrared Blue 160.0 µm
Herschel (SPIRE) Infrared Green 250.0 µm
Herschel (SPIRE) Infrared Yellow 350.0 µm
Herschel (SPIRE) Infrared Red 500.0 µm
